Name: Norton 750 Roadster Mk V
Brand: Norton

📖

İnceleme

⌄

None

⚙️ Teknik Özellikler

motor

Hacim

745.0 ccm (45.46 cubic inches)

Motor Detayları

360 degree parallel twin, air cooled.

Güç

58.0 HP (42.3 kW )) @ 6000 RPM

Tork

63.7 Nm (6.5 kgf-m or 47.0 ft.lbs)

Son Hız

186.7 km/h (116.0 mph)

Sıkıştırma Oranı

8.9:1

Çap x Strok

73.0 x 89.0 mm (2.9 x 3.5 inches)

Silindir Başına Valf

Yakıt Sistemi

Carburettor. Twin Amal 32mm Concentric Mk1 carburettors

Soğutma Sistemi

Air

Yağlama Sistemi

Dry sump high scavenging pump, separate oil tank

Ateşleme

Std points/coils. Fitted with Power Arc electronic system

Vites Kutusu

4-speed

Debriyaj

Laycock de Normanville diaphragm clutch, dry

Yakıt Tüketimi

3.62 litres/100 km (27.6 km/l or 64.98 mpg)

Sera Gazı (CO2)

84.0 CO 2 g/km. (CO2 - Carbon dioxide emission)

Egzoz Sistemi

Twin chrome pipes, upswept‘Peashooter’ Norton mufflers, rubber mounted

Marş

Kick

sasi

Şasi Tipi

2 1/4´ single backbone frame, twin cradle, isolastic mounting

Ön Süspansiyon

Norton Roadholder two way hydraulic damped

Ön Tekerlek Hareketi

152 mm (6.0 inches)

Arka Süspansiyon

Twin Girlinv shocks, spring load adjustable

Ön Frenler

Single disc. Twin piston Lockheed calliper with cast iron disc

Arka Frenler

Expanding brake (drum brake)

Ön Lastik

4.00-19

Arka Lastik

4.00-19

Jantlar

Stainless spoked, alloy rims, alloy hubs

boyut

Kuru Ağırlık

180.5 kg (398.0 pounds)

Güç/Ağırlık Oranı

0.3213 HP/kg

diger

Elektrik Sistemi

12 volt positive ground, 180 watt alternator, capacitor assisted

Işıklandırma

Lucas 65/50 watt quartz halogen. Replaced with LED

Göstergeler

Smiths speedo to 150 mph. Tachometer to 9000 rpm

Article ID

56221

Norton 750 Roadster Mk V
